Specifications

Panel Technology	IPS with Direct LED backlights
Screen Size	55 inch
Max. Brightness (average)	700 cd/m2
Contrast Ratio	> 3500:1
Viewing Angle (H/V)	178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Gamut	72% of NTSC
Response Time	8ms
Panel Refresh Rate (Hz)	60Hz
Haze Level (%)	25
Supported Orientation	Landscape, Portrait
Native Resolution	1920 x 1080
Supported Resolution	1024 x 768; 1080i; 1080p; 1280 x 1024; 1280 x 768; 1360 x 768; 1600 x 1200; 1920 x 1080; 3840 x 2160; 640 x 480; 720p (50/60 Hz); 800 x 600
Horizontal Frequency [kHz]	26 – 134
Vertical Frequency [Hz]	23 – 86
Input Video Analogue	1 x VGA; Composite (RCA)
Input Video Digital	1 x DVI-D (with HDCP); 1 x OPS Slot; 2 x DisplayPort (with HDCP); 2 x HDMI (with HDCP)
Input Audio Analogue	2 x 3.5 mm jack
Factory Calibration	Gamma; Intensity; RGB; Uniformity; White Point
Sensor Calibration	PC-less Calibration with USB Sensor MDSVSensor3; White Copy (post self-calibration)
OPS Slot	Slot Technology: Open pluggable specification (NEC / Intel OPS standard)
Max Power Consumption	3.6 / 58
Human Sensor	4-5m range, external, Optional, triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
NFC Sensor	2cm range, free NEC Android App required, Integrated
Power Consumption	180W shipping
Power Savings Mode	< 0.5; < 2 (Networked Standby)
Operating Temperature	0?C to 40?C
Operating Humidity	20% to 80%
Weight [kg]	28.1
Bezel Width [mm]	0.44 bottom/right; 0.44 top/left; 0.88
Dimensions (W x H x D) [mm]	1, 210.5 x 681.3 x 103

Seamless video walls to amplify your brand

Advanced intelligent features and imaging performance powered by SpectraViewTM ensure precise and consistent visualisation across the entire wall, The 55-inch Sharp MultiSync? UN553S creates the impression of a single, continuous surface for clear and engaging content presentation.

Engineered for 24/7 operation in public spaces, the series combines robust metal construction with advanced thermal management to deliver reliable, long-lasting performance. It delivers uncompromising quality and dependable operation for demanding applications in corporate and transportation environments and for mission-critical control room scenarios.

Benefits

Easy installation ? effortlessly set up you wall display with Auto TileMatrix and out-of-the-box calibrations. Save time by plugging in ready-to-use image presets for predefined application scenarios.

Enhanced imaging performance ? advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.

Lifelike and consistent colour ? expect colour reproduction that feels true to life with IPS panel technology, the top choice when it comes to colour consistency. The S-IPS panel ensures that perfect visibility is maintained in landscape and portrait mode and at extreme viewing angles as viewers pass by.

Secure Reliability and Longevity of Video Walls ? unique NEC heat management system enables the user to monitor and control the heat inside the display.

Cost Saving Device Management ? save effort whilst managing all connected NEC devices from a centralised location by using the NaViSet Administrator 2 software tool.
