Specifications

Panel Technology	IPS with Edge LED backlights
Screen Size	49 inch
Contrast Ratio	8000:1
Viewing Angle (H/V)	178
Response Time	8ms
Panel Refresh Rate (Hz)	60Hz
Haze Level (%)	28
Supported Orientation	Face Up & Face Down, Landscape, Portrait
Dimensions (W x D x H)	1103.4 x 61.1 x 636.2 millimetre
Bezel Width	12 (top); 12.5 (left & right); 15.6 (bottom) millimetre
Weight	22.9 kilogram
VESA Mounting [mm]	4 holes M6 300 x 300 (FDMI)
Native Resolution	3840 x 2160
Horizontal Frequency [kHz]	15 – 135
Vertical Frequency [Hz]	23-76
Aspect Ratio	16:9
Input Video Digital	2 x Display Port (with HDCP) 2 x HDMI (with HDCP)
Input Audio Digital	1 x Display Port, 2 x HDMI
Input Control	LAN 100Mbit Remote control wire (3.5mm jack), RS232
Compute Module Slot	RPi4 Compute Module
Intel SDM	Accepts Intel? Smart Display Modules Large and Small up to 66W
Installation	Face-up Face-down Landscape Portrait
Ambient Light Sensor	Integrated triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
Power Consumption	100-200W
Power Savings Mode	<0.5W (Normal Standby); 2W (Network Standby)
Operating Temperature	0?C to 40?C
Operating Humidity	20% to 80%
Safety and Ergonomics	CE, EAC, EMC Class B, Energy Star 8.0, PSB, RCM, RoHS, VCCI
Special Characteristics	DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo
Shipping Content (Accessories)	2x AAA Batteries, HDMI Cable, Power Cable, Remote Control, Setup Manual

When imaging precision cannot be compromised

Unparalleled clarity of detail and colour accuracy is achieved with 8K signal processing, wide colour gamut and the integrated SpectraView? engine controlling all visual parameters. Even in bright ambient light conditions, high brightness levels of 700 cd/m? combined with a high haze filter guarantees exceptional readability with no annoying reflections.

Despite its slim, elegant profile, the quality build is robust for use in public spaces, with an all-metal chassis for fire-retardancy. Featuring Open Modular Intelligence (OMI) slot-in technology, choose scalable computing power with Raspberry Pi Compute Module 4 or the more powerful Intel? Smart Display Modules (Intel?SDM) for tailor-made signage solutions.

Benefits

Secure remote management ? control your devices remotely and securely using NaviSet Administrator 2, proactively manage maintenance requirements saving time and resources.

Unhindered readability ? no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation.

Safe for public environments ? a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory.

Enhanced imaging performance advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.

Mission-critical 24/7 ready operation the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
