Specifications

Panel Technology	IPS with Direct LED backlights
Screen Size	86 inch
Max. Brightness (average)	450 cd/m2
Contrast Ratio	1200:1
Viewing Angle (H/V)	178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Depth [bn]	1.073 (10bit)
Colour Gamut	68% of DCI
Response Time (typ.) [ms]	8
Panel Refresh Rate (Hz)	60
Supported Orientation	Face Up; Landscape; Portrait
Native Resolution	3840 x 2160
Supported Resolutions
Touch Technology	InGlass? M5
Multi Touch	Real multi-touch up to 20 touches
Response Time [ms]	? 15
Screen Type	anti-glare coating; Zero Bonding, Premium toughened glass
Thickness [mm]	3
Haze Level (%)	4 ~ 8
Horizontal Frequency [kHz]	15 – 135
Vertical Frequency [Hz]	23 – 76
Input Video Digital	1 x DisplayPort (with HDCP); 1 x USB-C (with HDCP, 65 W); 2 x HDMI (with HDCP)
Input Audio Digital	1 x DisplayPort; 2 x HDMI
Input Control	LAN 100Mbit; RS232
Input Data	1 x USB 2.0 (Powered 5V/2A, Firmware Updates); 1 x USB 2.0 Type-B (Downstream); 2 x USB 2.0 (Downstream)
Input Touch	1 x USB 2 (Type-B); 1x USB Type-C (shared with video input)
Output Video Digital	1 x DisplayPort (loop through: DisplayPort, SDM slot-in PC)
Output Audio Analogue	1 x 3.5 mm jack
Output Control	1 x LAN 100Mbit
Intel SDM	accepts Intel? Smart Display Modules Large and Small up to 66 W
Ambient Light Sensor	Integrated, triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
Power Consumption	275W shipping
Power Savings Mode	<0.5W (ECO Standby); 2W (Network Standby)
Operating Temperature	0?C to 35?C
Operating Humidity	20% to 80% (no condensation)
Storage Temperature	-20?C to 60?C

Safeguarding security and promoting productivity in hybrid meetings

Featuring InGlass? M5 premium touch technology, users benefit from the most natural writing experience and advanced interactive functionality. The high brightness output, high haze panel and premium glass coating delivers best readability in well-lit meeting rooms, without distraction from reflections, glare or fingerprints.

The LA series supports orientation any which way, including face up, allowing table-top, tilted desk or multi-board side-by-side installations for up to three displays. Users can connect their own notebook, safely and securely via a USB-C connection, providing best versatility in hybrid meetings and spontaneous collaborative interactions.

The LA series integrates elegantly and seamlessly into high-end meeting rooms and boardrooms providing trusted long-life performance whilst making minimal energy demands.

Benefits

Most natural writing experience ? InGlass? M5 premium touch system supports patented pressure sensitivity using passive pens as well as Windows Ink and palm rejection.

Secure by design ? the non-Android platform with additional security features meets the highest IT security standards.

Optional Windows based Intel SDM slot-in PC ? driving unlimited versatility with powerful integrated computing. Includes Sharp?s Meeting Launcher for quick and easy access to your apps offering a secure and locked environment.

Increase your productivity ? benefit from a free one-year license for FlatFrog Board for Rooms. FlatFrog Board whiteboard software makes hybrid work easy and productive for everyone.

Energy efficiency ? built-in functionality including an ambient light sensor, human presence detection and eco modes help to reduce power consumption.
