Specifications

Panel Technology	IPS with Direct LED backlights
Active Screen Area	1, 428.48 x 803.52 mm
Aspect Ratio	16:9
Pixel Pitch	0.372 mm
Brightness	550 cd/m2
Contrast Ratio	8000:1
Viewing Angle (H/V)	178 horizontal / 178 vertical (typ. at contrast ratio 10:1)
Colour Depth [bn]	1.073 (10bit)
Colour Gamut	72% of NTSC
Response Time	8ms
Panel Refresh Rate (Hz)	60Hz
Haze Level (%)	25
Supported Orientation	Face Up; Landscape; Portrait
Native Resolution	3840 x 2160
Supported Resolution
Horizontal Frequency [kHz]	15 – 135
Vertical Frequency [Hz]	23-76
HDMI IN 1	Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; ARC; CEC
HDMI IN 2	Video Input; UHD (60 Hz) HDCP (2.2); Audio Input; CEC
HDMI OUT	Compute module, Option, Video Output; UHD (60 Hz) HDCP (2.2); Audio Output; Loop Through: HDMI IN 2
Factory Calibration	Gamma; Intensity; RGB; Uniformity; White Point
Calibration with Software	Corner Uniformity; Gamma; Intensity; RGB; Update Factory Calibration; White Point
Compute Module Slot	RPi4 Compute Module
Intel SDM	accepts Intel? Smart Display Modules Large and Small up to 66 W
Ambient Light Sensor	Integrated, triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
Human Sensor	optional via Eco Sensor (PNKTES1)
Power Consumption	135W shipping
Power Savings Mode	< 0.5; < 2 (Networked Standby)
Operating Temperature	0?C to 40?C
Operating Humidity	20% to 80%
Dimensions (W x H x D) [mm]	1, 454.5 x 832.4 x 59.5
Weight [kg]	26
VESA Mounting [mm]	400 x 400 (FDMI); 4 holes; M6

Built to perform, designed to last

The versatile solution for professional display applications, the Sharp MultiSync? M2 Series With native USB-C connectivity and broad compatibility with platforms such as Crestron, Cisco Webex, and Microsoft Teams, it enables seamless BYOD collaboration and future-ready integration, while 802.1x LAN support ensures enterprise-grade network security.

As part of the new Sharp-branded display family, the MultiSync? M2 Series builds on NEC?s legacy of quality and reliability to drive greater efficiency and long-term value. Its proven modular design supports custom computing options (Raspberry Pi or Intel? SDM) and flexible connectivity (e.g. AV-over-IP), ensuring lasting versatility, performance, and sustainability.

Benefits

Seamless meeting workflows ? a single USB-C cable transmits video, data, and power for instant, clutter-free meeting setups. As the established standard for modern collaboration spaces, USB-C supports frictionless BYOD experiences.

Unhindered readability ? a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment

Security assured ? 802.1x support over LAN enables high-level security for corporate networks, giving peace of mind for IT teams and enterprise environments.

Enhanced imaging precision ? when brand consistency and corporate identity are important, NEC?s SpectraView Engine provides full control over colour, gamma, and uniformity for accurate and impactful content.

Broad AV compatibility ? fully interoperable with leading meeting room platforms including Crestron (XiO Cloud), Cisco Webex, Q-Sys, and Microsoft Teams, ensuring effortless integration and future-proof scalability.
