Specifications

Panel Technology	IPS with Direct LED backlights
Screen Size	98 inch
Contrast Ratio	8000:1
Viewing Angle (H/V)	178
Response Time	8ms
Panel Refresh Rate (Hz)	60Hz
Haze Level (%)	28
Supported Orientation	Landscape, Portrait
Dimensions (W x D x H)	2194.7 x 84.3 x 1250.2 millimetre
Bezel Width	15.9 (left & right); 15.9 (top & bottom) millimetre
Weight	71.6 kilogram
VESA Mounting [mm]	4 holes M8 600 x 400 (FDMI)
Native Resolution	3840 x 2160
Horizontal Frequency [kHz]	15 – 135
Vertical Frequency [Hz]	23-76
Aspect Ratio	16:9
Input Video Digital	1 x Display Port (with HDCP) 2 x HDMI (with HDCP)
Input Audio Digital	1 x Display Port 2 x HDMI
Input Control	LAN 100Mbit Remote control wire (3.5mm jack), RS232
Compute Module Slot	RPi4 Compute Module
Intel SDM	Accepts Intel? Smart Display Modules Large and Small up to 66W
Installation	Landscape Portrait
Ambient Light Sensor	Integrated triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
Power Consumption	300-400W
Power Savings Mode	<0.5W (Normal Standby); 2W (Network Standby)
Operating Temperature	0?C to 40?C
Operating Humidity	20% to 80%
Safety and Ergonomics	EMC Class B, Energy Star 8.0, PSB, RCM, UL/C-UL, VCCI
Audio (Speakers)	Integrated Audio Amplifier (for optional speakers up to 2 x 15 W), Integrated Speakers (10W + 10W)
Shipping Content (Accessories)	2x AAA Batteries, HDMI Cable, Power Cable, Remote Control, Setup Manual

Intuitive professional content delivery

Great first impressions can make all the difference; presenting your business in the best possible way will boost your brand. With slim, modern styling, 24/7 operation and high haze panel to reduce reflections when ambient light is high, the M series is the professional way to deliver your message, yet at an attractive price point.

With the optional MediaPlayer or the more powerful Intel? Smart Display Module (Intel? SDM) computing device, you are primed and ready for intuitive signage creation delivering real-time media playback for exceptional visual experiences. For advertising, infotainment and meeting room applications, the M Series provides powerful, upgradable functionality and all the aesthetic appeal to effortlessly reflect your brand credentials.

Benefits

Modern and slim design ? robust yet elegant allowing for an unobtrusive integration into any application and environment.

Secure remote management ? control your devices remotely and securely using NaviSet Administrator 2; proactively manage maintenance requirements saving time and resources.

Unhindered readability ? no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation.

Mission-critical 24/7 ready operation ? the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.

Future Ready Connectivity ? featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.
