Specifications

Panel Technology	IPS with Direct LED backlights
Max. Resolution	3840 x 2160 pixels
Max. Brightness (average)	400 cd/m2
Viewing Angle (H/V)	178
Haze Level (%)	1
Supported Orientation	Landscape, Portrait
Dimensions (W x D x H)	1238.6 x 72 x 717.7 millimetre
Bezel Width	12.5 (left, right and top); 13.9 (bottom) millimetre
Weight	16.8 kilogram
VESA Mounting [mm]	4 holes M6 400 x 200 (FDMI)
Horizontal Frequency [kHz]	15 – 136
Vertical Frequency [Hz]	24-75
Supported Resolution	1280×720, 1920×1200, 2048×1080, 3840×2160, 4096×2160, 640×480, 720?576, 720×480
Input Video Analogue	1 x VGA Component (RCA); Composite (RCA)
Input Video Digital	3 x HDMI
Input Audio Analogue	1 x 3.5 mm jack
Installation	Landscape Portrait
Ambient Light Sensor	Integrated triggered actions programmable
Temperature Sensor	Integrated Triggered actions programmable 1 sensor
Power Consumption	100-200W
Power Savings Mode	<0.5W (Normal Standby); 2W (Network Standby)
Operating Hours	16/7
Operating Temperature	0?C to 40?C
Operating Humidity	10% to 80%
Supported Image Formats	360 x 8, 640, CMYK); max. resolution 15, JPG (baseline, progressive, RGB
Supported Video Formats	AAC; WMV (video H.264, audio WMA 9, H.263, H.264, HEVC/H.265); audio: LPCM, HEVC/H.265); TS (MPEG2, max res 1080p@30Hz, max res 1080p@30Hz); MP4 (MPEG2/4, MP3, MPG (MPEG1/2/4, Windows Media Video 9, WMA 10 Pro)
Safety and Ergonomics	EMC Class B, Energy Star 8.0, PSB, RCM, UL/C-UL, VCCI
Audio (Speakers)	Integrated Speakers (10W + 10W)

Functionality you need, at the price you want.

An integrated MediaPlayer supports native UHD resolution and High Dynamic Range (HDR) for deep contrasts and natural looking content playback with auto-play function. Requiring no additional cables, external devices or signage software, the USB MediaPlayer enables a simple seamless professional signage solution. Meanwhile, a 15W USB interface supports connection of external devices should additional computing power be required.

For instant start-up in meeting spaces, inputs are detected automatically with easy switching between HDMI sources. Facilities managers will welcome the ability to remotely control their digital estate via the network thanks to the integrated LAN and NaviSet Administrator 2 functionality making the E Series the perfect choice for corporate meeting rooms and entry level digital signage.

Benefits

Commercial Performance ? with 400cd/m2 brightness and supporting both Landscape & Portrait orientation, the E-series are a go-to commercial display.

Reduced Installation and Operating Costs ? highly energy efficient LED backlit display ensures low power consumption, longer backlight lifetime and lighter design for easy transportation, mounting and integration.

Slim Design and Integrated Speakers ? the aesthetic design is pleasing to the eye and enables easy, low cost installation.

Future Ready Connectivity ? featuring multiple industry standard digital and analogue signal inputs for flexible integration into AV infrastructures.

Standalone operation ? the display is designed for straightforward standalone operation due to integrated USB media player, speakers and scheduling functionality.

Effortless content playback ? the integrated USB media player supports various image video file formats for effortless and standalone content playback.
