Specifications

Panel Technology	IPS with Edge LED backlights
Screen Size	55 inch
Contrast Ratio	8000:1
Viewing Angle (H/V)	178
Response Time	8ms
Panel Refresh Rate (Hz)	60Hz
Haze Level (%)	28
Supported Orientation	Face Up & Face Down, Landscape, Portrait
Dimensions (W x D x H)	1239.6 x 61.1 x 713 millimetre
Bezel Width	12 (top); 12.5 (left & right); 15.6 (bottom) millimetre
Weight	27.6 kilogram
VESA Mounting [mm]	4 holes M6 300 x 300 (FDMI)
Native Resolution	3840 x 2160
Supported Resolution	1024×768, 1280×1024, 1280×720, 1366×768, 1440×900, 1600×1200, 1920×1080, 1920×2160, 2560×1600, 3840×2160, 4096×2160
Aspect Ratio	16:9
Input Video Digital	2 x Display Port (with HDCP) 2 x HDMI (with HDCP)
Input Audio Digital	1 x Display Port, 2 x HDMI
Input Control	LAN 100Mbit Remote control wire (3.5mm jack), RS232
Compute Module Slot	RPi4 Compute Module
Intel SDM	Accepts Intel? Smart Display Modules Large and Small up to 66W
Installation	Face-up Face-down Landscape Portrait
Ambient Light Sensor	Integrated triggered actions programmable
Temperature Sensor	3 sensors, Integrated, triggered actions programmable
Power Consumption	90W (shipping)
Power Savings Mode	<0.5W (Normal Standby); 2W (Network Standby)
Operating Temperature	0?C to 40?C
Operating Humidity	20% to 80%
Safety and Ergonomics	CE, EAC, EMC Class B, Energy Star 8.0, RCM, RoHS, VCCI
Special Characteristics	DICOM Simulation; HDMI ARC; Powered USB Port (10 W); Removable Logo
Shipping Content (Accessories)	2x AAA Batteries, HDMI Cable, Power Cable, Remote Control, Setup Manual

Meticulously powerful signage

For specialist applications, the wide colour gamut panel, SpectraView engine technology and 8K signal processing, positions the MA series at the high end of professional content delivery. The MA series? modular design includes Intel? Smart Display Module (Intel? SDM) technology integrated into the display, facilitating powerful media playback for the most intuitive signage creation and delivery. Featuring an integral audio amplifier, multi-picture mode technology and extensive connectivity including video out.

Benefits

Unhindered readability ? no reflections from windows or other light sources means no disruption to the visibility of signage content or meeting room presentation.

Wide colour gamut ? high-performance panel technology delivers a wider spectrum of colours for a superb visual experience.

Safe for public environments ? a metal back cover and intelligent heat management ensure safe use in public spaces where fire-retardancy is mandatory.

Enhanced imaging performance advanced settings of all relevant visual parameters allow full control of brightness, colour, gamma and uniformity via the SpectraView Engine for precise, natural images.

Mission-critical 24/7 ready operation the meticulous selection of industrial-grade components and careful design focused on demanding usage scenarios accompany an impressive and continuous viewer experience.
